Jhih Han Du

Jhih Han Du

Taoyuan City,Taiwan (R.O.C.)

Summary

With 16 years of experience in compound semiconductors, specializing in GaAs pHEMT, GaN HEMT, and InP laser technologies. Experienced in III-V technology development, process integration, yield improvement, and project management, with a track record of transferring GaAs and GaN HEMT products to high-volume production.

  • Co-developed 0.45µm GaN HEMT technology with NXP, increasing wafer production volume by six times within 2.5 years.
  • Released 0.25µm GaN HEMT technology within two years, meeting industry standards.
  • Improved ED mode pHEMT yield by 60% within nine months and increased wafer production volume by four times.
  • Improved LED light emission yield by 50% within six months and increased wafer production volume by eight times.

Goal-driven Principal Engineer adept at reviewing plans and implementing improvements. Skilled in technical research and expert in [Software]. Ready for new professional challenges and willing to take on dynamic responsibilities.

Overview

17
17
years of professional experience
5
5
years of post-secondary education

Work History

InP Laser R&D Principal Engineer

Win Semiconductors
Taoyuan City, Taiwan
01.2021 - Current

Company Overview: The company collaborated with strategic customers to customize 1550 nm for LiDAR application

  • Collaborated with a leading automotive LiDAR client to release 1550nm InP technology within two years
  • Worked with the laser diode team to release 1270-1390 nm DFB (CWDM) lasers, building WIN Semiconductors' optical communication technology within 2.5 years
  • Improved LED light emission yield by 50% within six months, while increasing wafer production volume by 8 times
  • The company collaborated with strategic customers to customize 1550 nm for LiDAR application

GaN R&D Project Manager

Win Semiconductors
Taoyuan City, Taiwan
01.2016 - 01.2021

Company Overview: The company customized a 0.45μm GaN-on-SiC process in 2016-2019 for base station, achieving mass production in 2019

  • Co-developed 0.45µm GaN HEMT technology with IDM, increasing wafer production volume by six times within 2.5 years
  • Shortened HTRB (High Temperature Reverse Bias) cycle time from 1 months to 3 days by implementing on-wafer quick testing
  • Resolved HTRB (High Temperature Reverse Bias) test issues, reduced leakage current by 1000 times, and kept pinch-off variation within 5%
  • Fixed HTOL (High Temperature Operating Life) test issues, reduced leakage current by 100 times, and maintained pinch-off voltage variation within 5%
  • The company customized a 0.45μm GaN-on-SiC process in 2016-2019 for base station, achieving mass production in 2019

GaN R&D Senior Engineer

Win Semiconductors
Taoyuan City, Taiwan
01.2010 - 01.2016

Company Overview: The company developed 4-inch 0.25μm GaN-on-SiC technology for radar and released it in 2012

  • Developed unit processes and integrated front- and back-side modules to produce GaN prototype products within one year
  • Released a 0.25µm GaN HEMT technology within two years, meeting industry leaders' performance standards
  • Collaborated with the GaN team to develop 0.45µm GaN-on-SiC HEMT technology, creating WIN Semiconductors' own technology within two years
  • Trained all new employees to help them become familiar with the GaN process
  • The company developed 4-inch 0.25μm GaN-on-SiC technology for radar and released it in 2012
  • Monitored employee performance to keep projects on task.

GaAs Integration Engineer

Win Semiconductors
Taoyuan City, Taiwan
01.2008 - 01.2010

Company Overview: The company's revenue CAGR was 41% from 2005 to 2011, exceeding the GaAs industry average of 12%, with a 50% market share and a goal to maintain an 85% yield against the IDM standard of 90%

  • Achieved a 60% yield improvement in ED mode pHEMT within nine months while increasing wafer production volume by 4 times
  • Took on integration tasks and gained experience in problem-solving and process improvement as a newcomer
  • The company's revenue CAGR was 41% from 2005 to 2011, exceeding the GaAs industry average of 12%, with a 50% market share and a goal to maintain an 85% yield against the IDM standard of 90%
  • Ensured seamless user experience by conducting thorough testing of integrated systems before deployment.

Education

Master of Science - Materials Science and Engineering

National Dong Hwa University
Hualien
09.2005 - 07.2007

Bachelor of Science - Materials Science And Engineering

National Dong Hwa University
Hualien
09.2002 - 07.2005

Skills

1 IDM project management

2 III-V technology from development to mass production

3 Compound Semiconductor Expertise : GaAs pHEMT, GaN HEMT, and InP laser

4 Risk Management and Analysis Skills: DFMEA, PFMEA

5 Yield improvement: WAT analysis, failure analysis, 8D, SPC, Cp, Cpk

6 DC and RF Testing

7 Reliability Enhancement: DCHTOL, HTRB

Publications

  • The Demonstration of Enhancement/Depletion-Mode pHEMT Technology with Optimized E-mode Characteristics for Better Yield
  • RF Performance Improvement of 0.25um GaN HEMT Foundry Technology.

Patents

  • Method to produce high electron mobility transistors with Boron implanted isolation., US9136345
  • Semiconductor structure for improving the gate adhesion and schottky stability., US10084109

Timeline

InP Laser R&D Principal Engineer

Win Semiconductors
01.2021 - Current

GaN R&D Project Manager

Win Semiconductors
01.2016 - 01.2021

GaN R&D Senior Engineer

Win Semiconductors
01.2010 - 01.2016

GaAs Integration Engineer

Win Semiconductors
01.2008 - 01.2010

Master of Science - Materials Science and Engineering

National Dong Hwa University
09.2005 - 07.2007

Bachelor of Science - Materials Science And Engineering

National Dong Hwa University
09.2002 - 07.2005
